Click to open expanded view
Input 120V 60 Hz
Output 24V DC 4.0 A
SEC 96W
PF >0.95
Efficiency >88%
Knockouts 2
Waterproof Rating IP67
Certification cUL us Listed, Class 2, Class P, Type HL, FCC compliant
Power Source Type Corded Electric
Included Components 96W Dimmable Driver
Color Black
Style 96W Dimmable LED Driver
SKU: PWR-D24V-096-65-U-D-J

96W Dimmable LED Driver, AC120V to DC24V Power Supply, Class 2, UL Listed, IP67

Style: 96W Dimmable LED Driver
Price
$85.99
Taxes and shipping calculated at checkout

96W Dimmable LED Driver, AC120V to DC24V Power Supply, Class 2, UL Listed, IP67

SKU
Style
Price
EMITEVER 96W Dimmable LED Driver,AC120V to DC24V Power Supply, Class 2 LED Transformer for LED Light Emitever
PWR-D24V-096-65-U-D-J 96W Dimmable LED Driver
$85.99
Compare product options
9976 in stock and ready for shipping

The Emitever 96W Triac Dimmable Voltage LED Driver is designed to operate with a stable flicker-free performance and meets high safety and performance standards.

  • IP67: This driver is perfect for both indoor and outdoor use.
  • Built in Protection: Includes standard built-in protections like auto-reset, short-circuit, overload, and over-temperature protection.
  • Damp Location Rated: Suitable for use in both dry and damp environments.
  • Easy to install: With its low-profile aluminum enclosure and two knock-outs.

Share this product

Converts your project's 120V AC line voltage to 24V.

Low-profile aluminum enclosure that includes two knock-outs for easy installation

Description

The Emitever 96W Triac Dimmable Voltage LED Driver is class 2 rated.

Designed to operate with any standard MLV/Incandescent TRIAC (Leading edge) dimmer switch.

It provides reliable and efficient power to a variety of LED lighting systems, ensuring a stable and flicker-free lighting experience.

The LED driver is easy to install with its low-profile aluminum enclosure and two knock-outs.

Follow the wiring instructions provided in the images for proper setup.

Product Features

Broad compatibility and smooth dimming performance with any standard MLV/Incandescent TRIAC (Leading edge) dimmer switch.

Stable Output: Offers 0-100% smooth and full-range flicker-free dimming.

24V: Ideal for DC24 LED lighting such as LED strips, modules, light bars, puck lights, under-cabinet lighting, and other LED accent lights.

IP67 Waterproof and Safety: With an IP67 waterproof rating, this driver is perfect for both indoor and outdoor use.

Built In Protection: It includes standard built-in protections like auto-reset, short-circuit, overload, and over-temperature protection.

Easy Installation: The LED transformer is encased in a low-profile aluminum enclosure that includes two knock-outs for easy installation.

Refer to the wiring instructions diagram in the images for detailed guidance.

Safety Features

Always verify connections before powering up.

Short Circuit Protection: Automatically shuts down to prevent damage and recovers after resolving the issue.

Overload Protection: Prevents the driver from overloading, ensuring safe and stable operation.

Over Temperature Protection: Shuts down the output voltage at high temperatures to prevent overheating and automatically recovers after cooling down.

Auto Reset: Built-in auto reset feature for added safety.

Certifications
  • UL Listed
  • Class 2
  • Class P
  • Type HL
  • FCC compliant
